Discussion on High-Density Interconnect Technology with Happy Holden
When it comes to miniaturization and high-frequency requirements, High-Density Interconnect (HDI) Printed Circuit Boards (PCBs) have become an indispensable solution for modern electronics. This article provides an overview of the key considerations and best practices for designing HDI PCBs.
Stack-up Architecture
HDI PCBs often feature intricate layer arrangements, with multiple lamination steps being common. Advanced designs may involve double lamination processes, supporting blind, buried, and microvias for dense interconnects and high-speed signals. Structures like (1+1+4+1+1) for 8-layer boards are common, balancing performance with manufacturing cost and yield [1][4]. Optimizing via placement can reduce lamination steps and lower costs while improving signal integrity.
Materials
The choice of materials plays a significant role in HDI PCB design, as they must withstand mechanical and thermal stresses during manufacturing and operation. High-performance laminates are essential to ensure dimensional stability, thermal management, and signal integrity. Selecting suitable laminates that can handle laser drilling for microvias is critical [1][3].
Testability
Due to tightly packed layouts and microvias, comprehensive testing for shorts, opens, and signal integrity is essential for reliability. Testing rigor often requires the assistance of the fabricator’s expertise for test planning. Ensuring test points and design for test (DFT) strategies are in place is key [1][3].
Necessity
HDI PCBs should be chosen when design constraints demand miniaturization, higher density, improved electrical performance (high frequencies), and stronger reliability. The benefits include size reduction, shortened signal paths, lower noise, and fewer through-hole vias, though at a higher manufacturing cost and complexity [2].
Controlled Impedance
Maintaining consistent trace widths and layer separations is vital to achieve specified impedance values. Signal integrity simulations and layout adjustments minimize impedance mismatches that degrade high-frequency performance [1].
Planning and Layout
Use specialized PCB design software with HDI-specific rules and constraints. Plan microvia placements carefully, consider via-in-pad technologies, and verify design rules against fabricator capabilities. Collaborate closely with the PCB manufacturer early for design feedback to ensure manufacturability and cost-effectiveness [1][3].
Thermal Management
High component density in HDI PCBs can cause heat buildup. Incorporate thermal vias and heat sinks to dissipate heat effectively, preserving reliability especially in power-intensive applications [1].
Manufacturing Precision
HDI requires laser drilling with tight tolerances (±10 micrometers) and fine line etching. Designing for manufacturability must consider these precision limits and the fabricator’s capability to handle microvias and controlled impedance layers [1].
Before embarking on an HDI design, it is essential to determine if HDI is necessary for the project. When working on a first HDI design, it is advisable to work closely with the fabricator, understand their testability guarantee, reliability, and the material's overall performance. It is also crucial to plan the design upfront to avoid running out of vias during the design process [5].
In HDI design, everything must be considered transmission lines because the package has used up the critical length. Adding hundreds of laser-drilled blind vias at the last step is a costly and inefficient way to finish an HDI design [6].
Lastly, it is worth mentioning that HDI materials are covered by IPC 4104, which brings about a new set of constraints and rules for designers [7]. To facilitate the design process, Happy Holden's "The HDI Handbook" is available for download [8]. A test vehicle is recommended for the first HDI design to ensure material and design viability, as the first design can be successful but may also be painful and costly without one [9].
In brief, HDI PCB design demands a holistic approach balancing electrical performance, mechanical constraints, manufacturing capabilities, and cost implications while leveraging advanced materials and stack-up technologies to meet miniaturization and high-frequency requirements effectively. Partnering closely with an experienced HDI PCB fabricator throughout the design process is strongly recommended to optimize the final product [1][2][3][4].
